- General Information
- Manufacturer
- Hikvision
- Manufacturer Website Address
- http://www.hikvision.com
- Brand Name
- Hikvision
- Product Line
- DeepinMind
- Product Series
- M
- Product Type
- Video Surveillance Station
- Technical Information
- Total Number of Channels
- 16
- Connectivity Technology
- Wired
- Recording Formats
- 8K
- HD Recording
- Yes
- System Components
- Network Video Recorder
- Video
- Video Formats
- H.264
- H.264+
- H.265
- H.265+
- Video Signal Format
- NTSC
- PAL
- Maximum Resolution
- 32MP
- Maximum Frame Rate
- 30 fps
- Network & Communication
- Ethernet
- Yes
- Remote Management
- Yes
- Interfaces/Ports
- USB
- Yes
- USB Standard
- USB 2.0/3.0
- Number of USB Ports
- 3
- Total Number of Audio In Ports
- 1
- Total Number of Audio Out Ports
- 1
- Number of VGA Out
- 1
- HDMI
- Yes
- Power Description
- Power Consumption
- 50 W
- Power Source
- AC Supply
- Physical Characteristics
- Height
- 2.80" (71 mm)
- Width
- 17.52" (445 mm)
- Depth
- 15.75" (400 mm)
- NVR Weight
- 5 kg
- Environmental Conditions
- Minimum Operating Temperature
- 14°F (-10°C)
- Maximum Operating Temperature
- 131°F (55°C)
- Miscellaneous
- Country of Origin
- China
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Waste Electrical and Electronic Equipment Directive (WEEE)
