The Intel® Omni-Path 1U Switch is a 1U rack-mountable switch with 48 QSFP28 ports. The 1U Switch cost-effectively supports a cluster of up to 48 servers, or provides an edge or core switch option for a larger fabric. This fixed configuration switch is a member of the Intel® Omni-Path Fabric series of switches, delivering an exceptional set of high-speed networking features and functions.
The Intel Omni-Path Switch is ideal for customers who deploy high-performance computing (HPC) clusters based on HPE ProLiant XL and DL Servers using the Intel Omni-Path technology.
- General Information
- Manufacturer
- Hewlett Packard Enterprise
- Manufacturer Website Address
- http://www.hpe.com
- Brand Name
- HPE
- Product Line
- Omni-Path
- Product Type
- Ethernet Switch
- Warranty
- Limited Warranty
- 3 Year
- Interfaces/Ports
- Uplink Port
- No
- Modular
- Yes
- Stack Port
- No
- Port/Expansion Slot Details
- 48 x 100 Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Optical Fiber
- Ethernet Technology
- 100 Gigabit Ethernet
- Network Technology
- 100GBase-X
- I/O Expansions
- Total Number of Expansion Slots
- 48.0
- Expansion Slot Type
- QSFP
- Management & Protocols
- Manageable
- No
- Power Description
- Power Source
- Power Supply
- Redundant Power Supply Supported
- Yes
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Rail-mountable
- Height
- 1.7"
- Width
- 17.3"
- Depth
- 16.8"
- Weight (Approximate)
- 14.70 lb
- Miscellaneous
- Package Contents
- Intel Omni-Path Architecture 100Gb 48-port Unmanaged Switch
- 2 x (1+1) Power Supplies
- 2 x Power cords, 6ft, C13-C14
- 6 x (N+1) Fans (customer selectable reverse airflow option)
- 19" rack rail kit (Rails have adjustable depth mounting from 26"-32")
- Quick Start Guide
- Certifications & Standards
- TÜV
- Environmentally Friendly
- Yes
