THINKSTATION & THINKPAD | P SERIES WORKSTATION FAMILY
Fostering creativity for professionals across industries
- General Information
- Manufacturer
- Lenovo Group Limited
- Manufacturer Website Address
- http://www.lenovo.com
- Brand Name
- Lenovo
- Product Line
- ThinkStation
- Product Series
- P5
- Product Type
- Workstation
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
- 3YR Premier NBD
- 3 Year On-site
- Technical Information
- AI-powered
- Yes
- Processor
- Number of Processors Supported
- 1
- Number of Processors Installed
- 1
- Processor Manufacturer
- Intel
- Processor Type
- Xeon
- Processor Model
- w3-2423
- Processor Speed
- 2.10 GHz
- L3 Cache
- 15 MB
- Processor Socket
- Socket LGA-4677
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- W790
- Memory
- Standard Memory
- 16 GB
- Maximum Memory Supported
- 512 GB
- Memory Technology
- DDR5 SDRAM
- Total Number of Memory Slots
- 8
- Error Checking
- ECC
- Memory Clock Speed
- 4.80 GHz
- Signal Processing
- Registered
- Storage
- Drive Type
- SSD
- Total Solid State Drive Capacity
- 512 GB
- Solid State Drive Interface
- PCI Express 4.0
- Solid State Drive Configuration
- 1 x 512GB
- Controllers
- Controller Type
- Serial ATA/600
- NVMe
- RAID Supported
- Yes
- RAID Levels
- 0, 1, 5
- Display & Graphics
- Number of Graphic Controllers
- 1
- Graphics Controller Manufacturer
- NVIDIA
- Graphics Controller Model
- RTX A400
- Graphics Memory Capacity
- 4 GB
- Graphics Memory Accessibility
- Dedicated
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Wireless LAN
- Yes
- Bluetooth
- Yes
- Interfaces/Ports
- Total Number of USB Ports
- 6
- Number of USB 2.0 Ports
- 2
- Number of USB 3.2 Gen 2 Ports
- 3
- USB Type-C
- Yes
- USB Type-C Detail
- 1x USB-C® (USB 20Gbps / USB 3.2 Gen 2x2), data transfer only
- Number Of Ethernet Ports
- 1
- Optional Ports
Details regarding optional ports aggregated from the information available for this product's family/series.
- Optional Front Ports 2x USB-C® (USB 10Gbps / USB 3.2 Gen 2), data transfer only 2x USB-A (USB 10Gbps / USB 3.2 Gen 2), one Always OnOptional Rear Ports1x Thunderbolt™ 4 (via additional PCIe® adapter) 1x serial 2x PS/2
- Input Devices
- Keyboard Localization
- French (Canada)
- Operating System
- Operating System Platform
- Windows
- Operating System
- Windows 11 Pro for Workstations
- Operating System Language
- French
- Operating System Architecture
- 64-bit
- Power Description
- Maximum Power Supply Wattage
- 1 kW
- Physical Characteristics
- Form Factor
- Tower
- Height
- 17.56" (446 mm)
- Width
- 6.50" (165 mm)
- Depth
- 17.87" (453.90 mm)
- Weight (Approximate)
- 41.89 lb (19000 g)
- Miscellaneous
- Package Contents
- ThinkStation P5 30GA00A0CA Workstation
- Keyboard
- Mouse
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
