- General Information
- Manufacturer
- Supermicro Computer, Inc
- Manufacturer Website Address
- http://www.supermicro.com
- Brand Name
- Supermicro
- Product Line
- SuperServer
- Product Type
- Server
- Warranty
- Limited Warranty
- 3 Year
- Processor
- Processor Type
- Xeon
- Processor Model
- D-2123IT
- Processor Core
- Quad-core (4 Core)
- Processor Speed
- 2.20 GHz
- Memory
- Memory Technology
- DDR4 SDRAM
- Total Number of Memory Slots
- 4
- Controllers
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
- RAID Levels
- 0, 1, 5, 10
- I/O Expansions
- Number of Total Expansion Bays
- 4
- Number of Internal 2.5" Bays
- 4
- Display & Graphics
- Graphics Controller Model
- AST2500
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- 10 Gigabit Ethernet
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Maximum Power Supply Wattage
- 600 W
- Physical Characteristics
- Form Factor
- Box PC
- Height
- 4.3"
- Width
- 10.5"
- Depth
- 16"
- Weight (Approximate)
- 17 lb
- Miscellaneous
- Package Contents
- SuperServer E403-9D-4C-FN13TP (Black)
- 1 x Super X11SDW-4C-TP13F Motherboard
- 1 x Embedded Server Box
- 1 x AOM-SDW-B16X2, Dual PCIE x16 Slot WIO Riser Card for Intel FlexRAN Project,RoHS
- 1 x Y Split , Big 4 Pin to Two RA SATA Power Extension 15cm, 18AWG
- 2 x SATA,INT,ROUND,ST-ST,29CM,30AWG
- 1 x CBL,VGA,DB15/F,w/Bracket TO 2X8F/P2.54,50CM,28/30AWG,RoHS
- 1 x 1U I/O Shield for X11SDW with EMI Gasket, Black
- 1 x Air Shroud for SC505 + X10SDV-7TP8F
- 1 x 1U 600/680W MULTI OUTPUT PWS 80+ GOLD
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
